REC 420AA PURE-R BLACK Mono Solar Panel for High Efficiency Reliable Solar Power

The REC 420AA PURE-R solar panel is at the forefront of solar technology, featuring 80 half-cut REC bifacial, heterojunction cells with advanced lead-free, gapless technology. Encased in 0.13 in (3.2 mm) solar glass with an anti-reflective surface treatment, it maximizes light absorption and minimizes reflection.

Key Features:

·       Cell Type: 80 half-cut REC bifacial, heterojunction cells

·       Glass: 3.2 mm thick with anti-reflective treatment

·       Backsheet: Highly resistant black polymer

·       Frame: Anodized aluminum in black

·       Junction Box: 4-part with 4 bypass diodes, IP68 rated

·       Connectors: Stäubli MC4 PV-KBT4/KST4 compliant with IEC 62852

·       Cable: 12 AWG PV wire, 67 + 67 in long

·       Dimensions: 68.1 x 44.0 x 1.2 in or 1730 x 1118 x 30 mm

·       Weight: 47.4 lbs

·       Origin: Made in Singapore

Specification Data sheet:                  Download Here

Performance and Warranty:

·       Low Light Behaviour: Superior performance under low irradiance

·       Temperature Ratings: Nominal Module Operating Temperature of 44°C (±2°C)

·       Power Output: 420 Wp

·       Efficiency: 21.8% panel efficiency

·       Warranty: Up to 25 years of product and power warranty, with labor warranty for installations by REC Certified Solar Professionals

Certifications:

·       Meets IEC 61215:2016, IEC 61730:2016, UL 61730, and other international standards

·       Lead-free according to RoHS EU 863/2015

·       Certified for resistance to salt mist, ammonia, and dynamic mechanical loads

Operational Excellence:

·       Operational temperature range from -40 to +85°C

·       System voltage up to 1000 V

·       High test load capacity with a safety factor of 1.5
